Product Description
1.Working principle
The watering truck utilizes the engine power of the vehicle itself to drive the onboard water pump through a power take-off device.
Water is drawn from the intake or the water in the tank is delivered to various nozzles through pipes, thereby achieving various functions.
The water pump on the watering truck serves the dual functions of water intake and pressurized water discharge.The self-priming pump can directly draw water from a pond into the tank,or it can also directly connect to a fire hydrant on city streets to fill the tank with water for watering operations.
2.Upper outfit configuration
Tonnage
Sprinkler trucks can be divided into various tonnages such as 1-3tons, 3-5tons,6-8tons,etc., according to thier water carrying capacity, to meet the needs of different scales of operations.
Multi-funcional spraying equipment
Including front spray,rear sprinkler, side spray, high-level flower spray, rear working platform, etc., to provide multi-funtional spraying operations
Tank manufacturing
The tank is made of Q235 carbon steel plate with thicknesses such as 3mm, 4mm, etc. Some people-purpose vehicles also use stainless steel materials.
3.Chassis Parameters
Drive Form
4X2 offers good passability, suitable for operations on complex terrains
OveTprall dimensions
8400,8650,8850x2500x3100,3250(mm), providing a larrger working space and ease of operation
Rated load capacity
10700,10765(kg), the vehicle has a high load-bearing capacity, suitable for carrying a large amount Inof spraying materials
Wheelbase
3950-5100mm,offers varying levels of stability and passability
Maixmum speed
88(km/h), provides a faster moving speed, improving work efficiency
Tire Size
10.00R20 18PR,295/80R225.5 16PR,275/80R22.5 18PR,providing varying load-carrying capacities and adaptabilities
USAGE SCENARIOS
1.Emergency Firefighting Function
Equipped with a high-pressure water cannon, it can be used as temporary fire truck, especially for rapid response at the early stages of a fire, provding long-distance fire extinguishing support.
2.Environmental Benefits
In the summer, it effectively reduces temperatures through watering, mitigates the urban heat island effect,and enhances the comfort level of the city
During dry seasons, it increases air humidity, reduces dust, improves air quality, and protects public health
3.Multipurpose Use
Road maintenance
Used for road cleaning, dust suppression, keeping the road surface moist, reducing the impact of dust on traffic and the enviroment
Greening spraying
Provides irrigation for plants and trees, maintaining green spaces in parks, gardens, and pubilc areas.
Construction work
Controls dust construction sites, moistens concrete, and provides water sources for construction activities.
High-altitude cleaning
Cleans the exterior walls of high-rise buildings and other elevated structures, maintaining the cleanliness and aesthetics of the city
4.Other Functions
Sprinkling
Provides sprinkling services for urban streets and rural roads, keeps the road surface moist, and reduces dust raising
Dust suppression
In dry or construction enviroments, reduces dust in the air by spraying water mist
Pesticide spraying
Sprays pesticides in agricultural or greening areas for pest and disease control
