Key Features and Technical Specifications
Effective Volume of the Container:
6m³, designed with a curved shape, enhancing both aesthetics and functionality.
Container Material: Made of 4mm thick T420 special steel on the sides and bottom, providing durability and resistance to wear and tear.
Compression Ratio:
≥2.5, ensuring efficient waste reduction.
Filler Volume:
≥0.8m³, with a cycle time of ≤25s for loading and ≤45s for unloading waste.
Control System:
Offers both automatic and manual control modes.
Hydraulic System:
Features a maximum pressure of 18MPa, with components like multi-way valves from Yangzhou Zhongmei and hydraulic pumps from Hefei Changyuan.
Cylinders and Tubes:
Utilizes high-quality hydraulic cylinders from Hunan Juge/Yantai Future and Tianhe oil tubes.
Electromagnetic Air Valve:
Bairin Pneumatics, enhancing the efficiency and precision of operations.
Control System:
Employs CAN-BUS bus control for seamless integration and operation.
Lifting Cylinder Balance Valve:
Imported from Italy, ensuring smooth and safe lifting operations.
Engine Power Control:
Fully automated for optimal power output during waste compaction and ejection cycles.
Tipping Mechanism:
Standard equipment includes two 240L tipping mechanisms, with options for various working devices.
Performance and Features
1. Electro-Hydraulic Combined Control:
The control system merges the benefits of electrical and hydraulic controls, enhancing reliability and efficiency.
2.Automatic Engine Power Output Control:
Adjusts the throttle automatically for power needs during waste compaction, minimizing power loss, reducing malfunction rates, and enhancing fuel economy.
3.Robust Frame Structure:
The garbage box is a solid frame structure made of reinforced beams and steel plates, with a rounded surface for an attractive appearance, lightweight, and effective force distribution.
