MAIN ADVANTAGES OF DONGFENG HUASHEN HOOK ARM GARBAGE TRUCK
Efficient and Environmentally Friendly Collection:
The truck offers a straightforward and efficient way to collect garbage, significantly reducing environmental impact as it avoids secondary pollution.
Reliable Quality with Low Failure Rate:
Renowned for its reliable performance, the truck boasts a low failure rate. It's easy to maintain, resulting in lower operational costs.
Versatile Applications:
Ideal for a variety of settings, the truck is widely used in municipal sanitation, city management, industrial and mining enterprises, residential complexes, and densely populated urban areas for effective waste management.
Advanced Upper Installation System:
Incorporating both domestic and international advanced technologies, the truck's upper installation system features a combination of remote control and manual operation, ensuring a safe, efficient, and industry-leading performance.
Hydraulic System:
Specially designed by our company, the hydraulic cylinders, pumps, and valves are produced by well-known domestic factories. They offer a perfect blend of performance and cost-effectiveness, with key parts featuring imported seals for stable and reliable quality.
Safety Features:
The truck includes several safety mechanisms, such as a built-in bidirectional unloading valve in the main oil cylinder, a balancing device in the lifting system, and dual-direction overload protection in the hydraulic system. These features ensure the safety of both personnel and the vehicle.
Durable Arm Structure:
Made of high-strength steel with special treatment in critical areas, the hook arm is robust and resistant to deformation.
Polished and Durable Upper Assembly:
The hook arm's upper assembly undergoes thorough polishing, rust removal, and multi-process painting to meet aesthetic and durability requirements. It's also rigorously tested to ensure top-notch quality.
Accompanying the truck are all necessary certifications, invoices, tools, maintenance manuals, and a national service station contact booklet, ensuring comprehensive after-sales support and maintenance ease.
MAIN ADVANTAGES OF DONGFENG HUASHEN HOOK ARM GARBAGE TRUCK
Efficient and Environmentally Friendly Collection:
The truck offers a straightforward and efficient way to collect garbage, significantly reducing environmental impact as it avoids secondary pollution.
Reliable Quality with Low Failure Rate:
Renowned for its reliable performance, the truck boasts a low failure rate. It's easy to maintain, resulting in lower operational costs.
Versatile Applications:
Ideal for a variety of settings, the truck is widely used in municipal sanitation, city management, industrial and mining enterprises, residential complexes, and densely populated urban areas for effective waste management.
Advanced Upper Installation System:
Incorporating both domestic and international advanced technologies, the truck's upper installation system features a combination of remote control and manual operation, ensuring a safe, efficient, and industry-leading performance.
Hydraulic System:
Specially designed by our company, the hydraulic cylinders, pumps, and valves are produced by well-known domestic factories. They offer a perfect blend of performance and cost-effectiveness, with key parts featuring imported seals for stable and reliable quality.
Safety Features:
The truck includes several safety mechanisms, such as a built-in bidirectional unloading valve in the main oil cylinder, a balancing device in the lifting system, and dual-direction overload protection in the hydraulic system. These features ensure the safety of both personnel and the vehicle.
Durable Arm Structure:
Made of high-strength steel with special treatment in critical areas, the hook arm is robust and resistant to deformation.
Polished and Durable Upper Assembly:
The hook arm's upper assembly undergoes thorough polishing, rust removal, and multi-process painting to meet aesthetic and durability requirements. It's also rigorously tested to ensure top-notch quality.
Accompanying the truck are all necessary certifications, invoices, tools, maintenance manuals, and a national service station contact booklet, ensuring comprehensive after-sales support and maintenance ease.
CONFIGURATION
Project | Details |
Overall dimensions | 7510×2500, 2550×3150(mm) |
Gross Vehicle Weight | 25000(Kg) |
Curb weight(kg) | 9200(Kg) |
Approach / departure angle | 18 / 25(°) |
Wheelbase | 1750+2550, 1900+2850, 1900+3500, 1900+3100(mm) |
Maximum speed | 88(km/h) |
Number of tires | 8 |
Front track | 1910 / 1910, 1940 / 1940(mm) |
Volume | 20m³ |
Engine model | YCS06220-60 |
Displacement (ML) | 6234 |
Rated load capacity | 15670, 15605(Kg) |
ABS | |
Front / rear suspension | 1410 / 1350(mm) |
Front and rear Axle Load | 7000 / 7000 / 11000 |
Number of axles | 3 |
Number of spring pieces | 9 / 9 / 10+8 |
Tire Size | 295 / 80R22.5 18PR, 11.00R20 18PR |
Rear track | 1860(mm) |
Transmission | |
Power(KW) / horsepower (PS) | 162kw / 220ps |
Fuel | Diesel |
CONFIGURATION
Project | Details |
Overall dimensions | 7510×2500, 2550×3150(mm) |
Gross Vehicle Weight | 25000(Kg) |
Curb weight(kg) | 9200(Kg) |
Approach / departure angle | 18 / 25(°) |
Wheelbase | 1750+2550, 1900+2850, 1900+3500, 1900+3100(mm) |
Maximum speed | 88(km/h) |
Number of tires | 8 |
Front track | 1910 / 1910, 1940 / 1940(mm) |
Volume | 20m³ |
Engine model | YCS06220-60 |
Displacement (ML) | 6234 |
Rated load capacity | 15670, 15605(Kg) |
ABS | |
Front / rear suspension | 1410 / 1350(mm) |
Front and rear Axle Load | 7000 / 7000 / 11000 |
Number of axles | 3 |
Number of spring pieces | 9 / 9 / 10+8 |
Tire Size | 295 / 80R22.5 18PR, 11.00R20 18PR |
Rear track | 1860(mm) |
Transmission | |
Power(KW) / horsepower (PS) | 162kw / 220ps |
Fuel | Diesel |
OTHER
Mainly used for garbage collection and transportation, and the main special device is the hook arm. Side protective material is Q235, connection mode welding connection; rear protective material Q235, connection mode bolt and welding connection, section size (mm): 12060, ground height (mm):450.ABS model and manufacturer: 3631010-C2000 / East Noel Commercial Vehicle Braking System (Shiyan) Co., Ltd. Install the travel recorder with the satellite positioning function. Install a directly powered ETC vehicle board. Corresponding relationship between engine and fuel consumption value (L / 100km): YCS06220-60 / 31.7, YCS06245-60 / 31.7, YCS06270-60 / 31.3. Only wheelbase 1900 + 2850 (mm) is selected. |
OTHER
Mainly used for garbage collection and transportation, and the main special device is the hook arm. Side protective material is Q235, connection mode welding connection; rear protective material Q235, connection mode bolt and welding connection, section size (mm): 12060, ground height (mm):450.ABS model and manufacturer: 3631010-C2000 / East Noel Commercial Vehicle Braking System (Shiyan) Co., Ltd. Install the travel recorder with the satellite positioning function. Install a directly powered ETC vehicle board. Corresponding relationship between engine and fuel consumption value (L / 100km): YCS06220-60 / 31.7, YCS06245-60 / 31.7, YCS06270-60 / 31.3. Only wheelbase 1900 + 2850 (mm) is selected. |
